MECALAC Manuals PDF

Above on the page there are several PDF Parts Manuals for MECALAC Excavators, Loaders.

Ahlmann is a part of Mecalac.

Mecalac backhoe loaders are produced in England and have previously been marketed on the world market under the Terex brand.

The French Mecalac Construction Equipment UK Ltd bought a division for the production of these machines back in 2016 and transferred it under its own brand.

Consumers are offered the entry-level model TLB 870 with a payload capacity of 3759 kg with a Perkins 1104D engine with a capacity of 96 hp, a loader bucket of 1 m3 and a backhoe of 0.24 m3.

Also available is the TLB 890 PS model with a lifting capacity of 3966 kg with a 1.2 m3 bucket and a 100 hp Perkins 1104D-44TA engine.

The backhoe loader is equipped with a closed hydraulic system, a soft boom suspension system, an automatic transmission and hydraulic wiring.

Mecalac TLB 990 PS is similar in technical parameters to the 890 model, but it differs in a higher level of comfort, equal wheels and a height of the loading bucket.

Backhoe control in all three models in the basic configuration is realized with a joystick.
